6x4 Single Axle Box Trailer with Hot-Dip Galvanized Silver Finish and 750kg ATM Tilt Feature

MOQ:	1
Payment Terms:	L/C,D/A,T/T,D/P
Supply Ability:	Annual output :2000

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

9001/TS 16949、CCC、CE、ADR、DOT

Document:

Name:

Single Axle Box Trailers

Trailer Dimensions:

6 Feet X 4 Feet

Hitch Pin:

70x50x3 Millimeters

Internal Dimensions:

1830mm × 1220mm

Surface Treatment:

Hot-dip Galvanizing

Color:

Silver

Light:

LED ADR Light

Shaft:

40mm Solid Square Steel

750KG

Net Weight:

358 Kg

Guide Wheel:

6 "rotation"

Safe Welding:

Pattern Plate:

2.0 Pattern

Tilt The Fuselage:

Side:

300mm X 2.0mm Fold

Pause:

5 Leaves

Beam:

50*50*3mm

Tire:

165/70R13C - Light-duty Truck

Braking:

No Brakes

Supply Ability:

Annual output :2000

Highlight:

6x4 Single Axle Box Trailers

Single Axle Box Trailers Silver

Box Tilt Trailer 750kg

Product Description

6x4 Single Axle Box Trailers Silver Box Tilt Trailer 750kg ATM

Premium 6x4 Single Axle Hot-Dip Galvanised Tilting Box Trailer with 750kg Aggregate Trailer Mass (ATM) rating. Built for durability and functionality with advanced corrosion protection.

Key Specifications

Trailer Dimensions	6 feet x 4 feet (1830mm × 1220mm internal)
ATM Rating	750kg
Net Weight	358 kg
Hitch Pin	70x50x3 millimeters
Axle Shaft	40mm solid square steel
Tire Specification	165/70R13C - Light-duty truck
Braking System	No brakes

Premium Features

Hot-dip galvanized surface treatment for superior corrosion resistance
Silver finish for professional appearance
LED ADR compliant lighting system
Tilting fuselage design for easy loading and unloading
6" rotation guide wheel for improved maneuverability
2.0 pattern plate construction
300mm x 2.0mm fold sides
5-leaf suspension system
50x50x3mm beam construction
Safe welding throughout for structural integrity
