Trailer dimensions:4255mm*2100mm*2400mm(Climb the ladder:2000mm)
Drawbar:100*50*4,1530 long
Internal dimensions:2700mm*1500mm*400mm
Surface treatment:Hot-dip galvanizing
Color:Silver
Light:LED ADR light
Axis:60 square steel bars, single-axis sinking axle*2, 12-inch electric brakes
Rated load capacity:2510kg
Weight of the skin:990kg
Guide wheel:8 inches
Fully welded:Yes
Patterned panel:2.3 pattern
Leaf spring: 8 leaf springs×2
Beam:80*40*3
Tire:185R14LT
Brake:Emergency brake
Connector:3.5-ton ball cover connector 17/8
Plug:7-pin flat plug
Climbing ladder distance:870-630
Rear outrigger:×2
Angle:13.44
Certification:9001/TS 16949,CCC,CE,ADR,DOT
